DOM (Document Object Model) is a tree structure of the HTML document. When we built a webpage, the browser needs to go from this HTML document to a styled page that we see in the viewport, this process is called Critical Rendering Path. We can break this process into several small steps. Now we can group this process into two stages: First stage and Second stage. In first stage, the browser parses the document to determine what will ultimately to be rendered on the page, and In the second stage, the browser performing the render.
To build a render tree, the browser needs:
- The CSSOM, the style associate with elements is represented
- The DOM, representation of element
DOM(Document Object Model)
Document Object Model(DOM) is an object based representation of HTML document. It converts HTML document to a object model, it has a tree like structure called a node tree. It is so called because it has only one parent node(root element).
Go with this example,
<!doctype html> <html lang="en"> <head> <title>A Web Page</title> </head> <body> <h1>Heading</h1> <p>sub-heading</p> </body> </html>
The representation of this HTML document is:
Don't misunderstand DOM as the one you see in the DevTool(inspect element in the browser). There are only a slight difference between both. It doesn't include pseudo-elements (e.g. ::after) and
tag will not be there in the DevTool.
If the html document you have created is invalid, it will automatically make changes and make it into a valid structure.
MySQL replication is a process that enables data from one MySQL database server (the master) to be copied automatically to one or more MySQL database servers (the slaves). It is usually used to spread read access on multiple servers for scalability, although it can also be used for other purposes such as for failover, or analysing data on the slave in order not to overload the master
This tutorial will cover a very simple example of mysql replication.For the process to work you will need two IP addresses: one of the master server and and one of the slave
10.0.0.207 - Master Database 10.0.0.205 - Slave Database
This article assumes that you have root privilege and installed mysql in both servers.
Configure the master database.
Open up the mysql configuration and add the following lines to the file or uncomment those lines if already exist.
# vi /etc/my.cnf bind-address = 127.0.0.1 bind-address = 10.0.0.207 #this is the ip adress of master servre. server-id = 1 #this number should be unique. log_bin = /var/log/mysql/mysql-bin.log
Note:- Create the above file is not exists and change owner and group to mysql.
binlog_do_db = newdatabase
Note: Here we use newdatabase for the replication. You can add any number of databases by repeating the line multiple times with mentioning database name.
After you make all of the changes, go ahead and save and exit out of the configuration file.
Then restart Mysql
# systemctl restart mysql
Open Mysql shell.
We need to grant privileges to the slave. You can use this line to name your slave and set up their password. The command should be in this format:
GRANT REPLICATION SLAVE ON . TO 'slave_user'@'%' IDENTIFIED BY 'password'; FLUSH PRIVILEGES;
To accomplish the task you will need to open a new window or tab in addition to the one that you are already using a few steps down the line.
Switch to the datebase:
Following that, lock the database to prevent any new changes:
FLUSH TABLES WITH READ LOCK;
SHOW MASTER STATUS;
You will see a table that should look like this:
+------------------+----------+-----------------+------------------+ | File | Position | Binlog_Do_DB | Binlog_Ignore_DB | +------------------+----------+-----------------+------------------+ | mysql-bin.000001 | 342 | newdatabase,has | | +------------------+----------+-----------------+------------------+
This is the position from which the slave database will start replicating. Record these numbers, they will come in useful later.
If you make any new changes in the same window, the database will automatically unlock. For this reason, you should open the new tab or window and continue with the next steps there.
Proceeding the with the database still locked, export your database using mysqldump in the new window (make sure you are typing this command in the bash shell, not in MySQL).
# mysqldump -u root -p --opt newdatabase > newdatabase.sql
Now, returning to your your original window, unlock the databases (making them writable again). Finish up by exiting the shell.
UNLOCK TABLES; QUIT;
Now you have completed configuring master database.
Configure the Slave Database
Log into your slave server, open up the MySQL shell and create the new database that you will be replicating from the master (then exit):
CREATE DATABASE newdatabase; EXIT;
Import the database that you previously exported from the master database.
Note: Here we export old data's to the database, don’t worry all the new data after the replication will automatically saved to the slave database.
mysql -u root -p newdatabase < /path/to/newdatabase.sql
Now we need to configure the slave configuration
# vi /etc/my.cnf Add following lines to the file. Server-id = 2 relay-log = /var/log/mysql/mysql-relay-bin.log log_bin = /var/log/mysql/mysql-bin.log binlog_do_db = newdatabase
Save the file.
Restart MySQL once again:
# systemctl restart mysql
The next step is to enable the replication from within the MySQL shell.
Open up the the MySQL shell once again and type in the following details, replacing the values to match your information:
CHANGE MASTER TO MASTER_HOST='10.0.0.207’,MASTER_USER='slave_user', MASTER_PASSWORD='password', MASTER_LOG_FILE='mysql-bin.000001', MASTER_LOG_POS= 342;
Note : on the above command change the following as per your data.
MASTER_HOST MASTER_USER MASTER_PASSWORD MASTER_LOG_FILE MASTER_LOG_POS
Then , Activate the slave server:
START SLAVE; SHOW SLAVE STATUS\G
You be able to see the details of the slave replication by typing in above command.
If there is an issue in connecting,
SET GLOBAL SQL_SLAVE_SKIP_COUNTER = 1; SLAVE START;
Try this command.
All done. Please test it is working fine by adding a sample table in master database.
Thank you for reading !!
